Celestion CF18VJD 18" Sub Bass

Huge magnet and motor assembly provides 3,2KW power handling and high sensitivity
R18,000.00
Qty:
  • Out of Stock
Print
Celestion's CF series is their latest, most technologically advanced range of high performance loudspeakers and is to be found in many top speaker brand high end designs.

The CF18VJD offers high efficiency with huge extended, tight and powerful bass response and massive power handling.  It offers the following features
A lightweight, robust cast chassis designed to minimise reflection back to the cone to reduce acoustic distortion
Balanced airflow venting to maximise voice coil cooling to control thermal compression and increase power handling
FEA optimised magnet topology ensures even distribution of magnet flux in the air gap.
Double suspension systems with "flexiroll" surrounds ensure maximum control of the cone over large excursions.
A 5" dual layer, inside/outside voice coil with glass fibre former provides massive power handling and efficient cooling.

General Specifications
Nominal Diameter18 inch, 460 mm
Power rating1,600W AES, 3,200W continuous. 6,400W peak
Nominal Impedance8 Ohms
Sensitivity97 dB 1W 1M
Frequency Range25-1,500 Hz
Resonance Frequency34.5 Hz
Xmax12 mm
Qts0,309
Vas145.8 l
Voice Coil Diameter5", 125 mm
Voice Coil ConstructionDual layer in/outside wound round copper
Former MaterialGlass fibre
Cone MaterialCarbon and Kevlar loaded paper
Chassis TypeCast Aluminium
MagnetFerrite, 174 Oz, 4.93 Kg
Total Weight50.6 lb, 23 Kg
Suggested enclosureHorn loaded or 80-100l ported at 40Hz.
